Hot Selling High Quality 2 Seats Electric Golf Cart

GH-L2

Power system

1. Motor: Germany Mahler 48V AC motor 2.Power: 5KW Electrical system: 48V 3.battery: 48V150ah lead-acid 4.maintenance-free battery charger: intelligent on-board charger 48V / 25A, charging time <8 hours (discharge rate 80%)

5.Controller: Total intelligent 48V / 350A with CAN communication function

6.DC: High-power non-isolated DC-DC 48V / 12V-300W controller

Basic Configuration

External dimensions

2520*1340*2050mm

Net weight

≦550kg（No battery）

Rated occupant

2 persons

Front and

rear track

1005mm/1075mm

Wheelbase

1690mm

Minimum ground clearance

170mm

Minimum turning radius

3.2m

Top speed

30KM/H

Driving private enjoy

Gradeability

20%

★First class seats (integral foam forming seat cushion + solid color premium imported leather)                                                 ★Anti-skid floor, corrosion resistance and aging resistance

Pope performance

20%

Maximum driving mileage

50-70Km (Ping Road)

Braking distance

＜3.5m

Suspension and brake system：

  ★Front suspension: double swing arm independent front suspension + spiral spring + cylinder hydraulic shock absorption.

★Rear suspension: integral rear axle, speed ratio 16.2:1, spiral spring shock absorption + cylinder hydraulic shock absorption + rear stabilizer bar

★Brake system: zero cross rear axle: four-wheel hydraulic brake, four-wheel disc brake + electronic brake parking (with vehicle traction function)

 ★Steering system: bidirectional gear rack steering system, automatic clearance compensation function                                                                                                                                                                              ★Frame: high-strength sheet metal trapezoidal frame

Factory configuration

platfond

Grsted black square pipe frame + PP material injection molding ceiling

 standard configuration

The front gear

DOT certified flip glass

 standard configuration

Safety strap

DOT certified two-point seat belt

 standard configuration

Body

Front cover, seat bucket, body, rear tail cover by automobile special injection molding; frosted black square pipe ceiling column;

 standard configuration

Floor

Anti-skid floor, high-strength structure, corrosion resistance, aging resistance

 standard configuration

Dashboard

Injection molding instrument panel, waterproof double gear electric lock switch, double arm combination switch, water cup holder; 12V power supply, double USB charging.

 standard configuration

Seat

Solid color premium imported leather (including: ball bag bracket)

 standard configuration

Hub

12-Inch Aluminum Wheel   Size:12x7  PCD: 4/101.6

 standard configuration

Tire

DOT certification; All-terrain 23*10.5-12 (4 Ply Rated) / tire

 standard configuration

 rearview mirror

Left and right of a manual adjustable, with a turn signal, folding outside the rearview mirror

 standard configuration

Lights and warning signals

LED front combination light (near light, high beam, turn signal, daily running light, position light) LED rear taillight (brake light, position light, turn signal); snail horn, reversing buzzer.

 standard configuration

Color and pattern

Standard color (forest green, ivory white, sapphire blue, apple red, metal black, crystal ash)

 standard configuration

Choose accessories

Rear basket
